WireGuard Portal

A simple, web based configuration portal for WireGuard. The portal uses the WireGuard wgctrl library to manage existing VPN interfaces. This allows for seamless activation or deactivation of new users, without disturbing existing VPN connections.

The configuration portal supports using a database (SQLite, MySQL, MsSQL or Postgres), OAuth or LDAP (Active Directory or OpenLDAP) as a user source for authentication and profile data.

Features

• Self-hosted and web based
• Automatically select IP from the network pool assigned to client
• QR-Code for convenient mobile client configuration
• Sent email to client with QR-code and client config
• Enable / Disable clients seamlessly
• Generation of wgX.conf if required
• IPv6 ready
• User authentication (database, OAuth or LDAP)
• Dockerized
• Responsive web UI written in Vue.JS
• One single binary
• Can be used with existing WireGuard setups
• Support for multiple WireGuard interfaces
• Peer Expiry Feature
• REST API for management and client deployment (coming soon)

Configuration

You can configure WireGuard Portal using a yaml configuration file. The filepath of the yaml configuration file defaults to config.yml in the working directory of the executable. It is possible to override the configuration filepath using the environment variable WG_PORTAL_CONFIG. For example: WG_PORTAL_CONFIG=/home/test/config.yml ./wg-portal-amd64.

Configuration Options

The following configuration options are available:

configuration key	parent key	default_value	description
admin_user	core	admin@wgportal.local	The administrator user. This user will be created as default admin if it does not yet exist.
admin_password	core	wgportal	The administrator password. If unchanged, a random password will be set on first startup.
editable_keys	core	true	Allow to edit key-pairs in the UI.
create_default_peer	core	false	If an LDAP user logs in for the first time, a new WireGuard peer will be created on the WG_DEFAULT_DEVICE if this option is enabled.
self_provisioning_allowed	core	false	Allow registered users to automatically create peers via their profile page.
import_existing	core	true	Import existing WireGuard interfaces and peers into WireGuard Portal.
restore_state	core	true	Restore the WireGuard interface state after WireGuard Portal has started.
log_level	advanced	warn	The loglevel, can be one of: trace, debug, info, warn, error.
log_pretty	advanced	false	Uses pretty, colorized log messages.
log_json	advanced	false	Logs in JSON format.
ldap_sync_interval	advanced	15m
start_listen_port	advanced	51820
start_cidr_v4	advanced	10.11.12.0/24
start_cidr_v6	advanced	fdfd:d3ad:c0de🔢:0/64
use_ip_v6	advanced	true
config_storage_path	advanced
expiry_check_interval	advanced	15m
use_ping_checks	statistics	true
ping_check_workers	statistics	10
ping_unprivileged	statistics	false
ping_check_interval	statistics	1m
data_collection_interval	statistics	10m
collect_interface_data	statistics	true
collect_peer_data	statistics	true
collect_audit_data	statistics	true
host	mail	127.0.0.1
port	mail	25
encryption	mail	none
cert_validation	mail	false
username	mail
password	mail
auth_type	mail	plain
from	mail	Wireguard Portal noreply@wireguard.local
link_only	mail	false
callback_url_prefix	auth	/api/v0
oidc	auth	Empty Array - no providers configured
oauth	auth	Empty Array - no providers configured
ldap	auth	Empty Array - no providers configured
provider_name	auth/oidc
display_name	auth/oidc
base_url	auth/oidc
client_id	auth/oidc
client_secret	auth/oidc
extra_scopes	auth/oidc
field_map	auth/oidc
registration_enabled	auth/oidc
provider_name	auth/oidc
display_name	auth/oauth
base_url	auth/oauth
client_id	auth/oauth
client_secret	auth/oauth
auth_url	auth/oauth
token_url	auth/oauth
redirect_url	auth/oauth
user_info_url	auth/oauth
scopes	auth/oauth
field_map	auth/oauth
registration_enabled	auth/oauth
url	auth/ldap
start_tls	auth/ldap
cert_validation	auth/ldap
tls_certificate_path	auth/ldap
tls_key_path	auth/ldap
base_dn	auth/ldap
bind_user	auth/ldap
bind_pass	auth/ldap
field_map	auth/ldap
login_filter	auth/ldap
admin_group	auth/ldap
synchronize	auth/ldap
disable_missing	auth/ldap
sync_filter	auth/ldap
registration_enabled	auth/ldap
debug	database	false
slow_query_threshold	database
type	database	sqlite
dsn	database	sqlite.db
request_logging	web	false
external_url	web	http://localhost:8888
listening_address	web	:8888
session_identifier	web	wgPortalSession
session_secret	web	very_secret
csrf_secret	web	extremely_secret
site_title	web	WireGuard Portal
site_company_name	web	WireGuard Portal

What is out of scope

• Generation or application of any iptables or nftables rules.
• Setting up or changing IP-addresses of the WireGuard interface on operating systems other than linux.
• Importing private keys of an existing WireGuard setup.

Application stack

• Gin, HTTP web framework written in Go
• Bootstrap, for the HTML templates
• Vue.JS, for the frontend

License

• MIT License. MIT or https://opensource.org/licenses/MIT
